A diagonal brace member frames into a gusset plate assembly along a working point alignment. A vertical structural member connects to the same gusset plate with bolted fasteners and splice plates. A bottom chord member provides support at the base with a designated thirty-degree angle orientation.
WP CL DIAG CL VERT T.O.S. CL HORD NOTE 1 CONNECTION PER VERTICAL, SIM OPP 14/S6.10 30°
