Damper support framing occurs at a concrete slab edge supported by a structural steel beam and hollow structural section column. A concrete slab on metal deck features a four inch minimum slope and additional number four reinforcing bars at twelve inches on center with hooked U-bars. An eight by eight by three-eighths inch embedded plate with four three-quarter inch studs anchors the assembly at the slab edge. A one inch gap separates the slab edge from the vertical metal studs and damper assembly below.
GL GL CONCRETE SLAB ON METAL DECK RE: PLAN STEEL BEAM RE: PLAN T/SLAB RE: PLAN RE: ARCH 4" MIN SLOPE RE: ARCH HSS RE: ELEVATION METAL STUDS RE ARCH DAMPER RE ARCH EDGE OF SLAB RE: ADDITIONAL #4@12" (HOOKED BAR/U-BAR) RE ARCH 1 1/2" TYP 1" GAP 8''X8''X 3/8'' EMBD PL W/ (4) 3/4'' STUDS 4 S-61301 IMP RE ARCH RE: ARCH
