Metal deck panels splice over steel beams per plan with specified end and intermediate support welds. A splice joint occurs over beam flanges less than two inches in width requiring a minimum two inch lap. Longitudinal support welds follow the weld schedule. Details show both same deck direction and change in deck direction conditions.
2" MIN LAP FOR BM FLANGES LESS THAN 2" IN WIDTH LONGITUDINAL SUPPORT WELD PER SCHED SPLICE JOINT BM PER PLAN END AND INTERMEDIATE SUPPORT WELD PER SCHED BM PER PLAN A SAME DECK DIRECTION B CHANGE IN DECK DIRECTION
