Structural · S-YSGZF

Column Base Plate Plan Detail with Gusset Plate

Materials

Steel

Elements

Anchors / Embeds Connections / Plates

Connections

Gusset Plate Base Plate / Anchorage Embed Plate

About this detail

A column base plate plan view with an attached gusset plate and multiple anchor rods. The assembly features two-inch minimum edge distances and six-inch spacing from centerlines, accompanied by additional one-and-a-half-inch diameter Grade 105 anchor rods where required by design calculations. Typical anchor rods are specified per schedule with matching embedment depths. The gusset plate aligns with the column centerline and base plate layout.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
