An exterior wall assembly featuring a hollow structural section girt supported above a concrete masonry unit wall. A continuous one-quarter-inch by nine-inch steel plate bears on the masonry wall below the girt. A three-sixteenth-inch fillet weld secures the structural steel girt assembly. Exterior wall panels and seismic slip joints are coordinated per architectural drawings.
2'-10" GRID CONT PL1/4X9 3/16 2-12 HSS GIRT PER EL 2-12 8" 1" WALL PANEL PER ARCH DWG A-351 - A-353 SSJ PER ARCH DWG A-441 - A-444 CMU WALL PER PLAN
