A steel beam or truss joist connects to a supporting truss girder utilizing a custom plate layout and fillet welds. A half-inch by eight-inch by twenty-four-inch plate is positioned at grid location 23A with five-sixteenths inch fillet welds. Three-quarter-inch by five-inch wide plates are attached to each side of the web typically. A section view X-X details the profile of the connected members and plate positioning.
BEAM SEE PLAN 1'-0" PLATE 3/4"x5" WIDE EA SIDE OF WEB (TYP) 3" TRUSS JOIST OR WF SEE PLAN TRUSS GIRDER SEE PLAN 5/16 5 SD3 PL 1/2"x8"x24" @ 23A 5/16 @ 23A X-X X-X SECTION 3" P.P.
