A wide-flange column supports a wide-flange collector beam on each side connected through a shear tab per schedule. A wide-flange girder frames into the column web with a shear tab sized per plan, with a W27 shown on the far side. Metal floor decking spans continuously across the top flanges of the beams.
1 WF COLLECTOR BEAM PER PLAN, SHEAR TAB TO COLUMN PER SCHEDULE 1 2 WF COL PER PLAN 3 WF24 GIRDER PER PLAN, SHEAR TAB TO COL WEB PER PLAN, W27 SHOWN FAR SIDE 2 1 3
