A 600S162-54 cold-formed steel member runs vertically without splices along the ends of the framing. A 600T150-44 track section fastens to the top and bottom flanges with number ten screws in each leg, also installed without splices. Joists per section frame into the assembly, secured by two number ten screws spaced at twelve inches on center through the vertical web.
