A concrete wall features an opening flanked by eight number five bars spaced equally on each face. A thirty-inch deep lintel spans the top of the opening, reinforced with two number five bars at both the top and bottom, alongside number three stirrups at twelve inches on center. Number three ties are provided at six inches on center extending from two feet below the opening to two feet above the opening.
OPEN (8) #5 BARS EQ SPACED., E.F. PROVIDE #3 TIES AT 6" O.C. FROM 2'-0" BELOW OPENINGS TO 2'-0" ABOVE OPENINGS. 30" DEEP LINTEL WITH (2) #5 BARS, TOP AND BOTTOM, WITH #3 STIRRUPS AT 12" O.C. (8) #5 BARS AT 8" O.C. E.F PROVIDE #3 TIES AT 6" O.C. FROM 2'-0" BELOW OPENINGS TO 2'-0" ABOVE OPENINGS. 7 S201 53 TO 52
