An open web steel joist is supported by a hollow structural section 6x6x1/4-inch ladder column using 3x3x1/4-inch angles on each side. Two L3x3x1/4-inch angle braces provide lateral stability beneath the metal roof deck. A three-sixteenths inch fillet weld secures the connection, leaving the column explicitly left unwelded to the angle.
MTL ROOF DECK TS 6x6x1/4" LADDER COL L 3x3x1/4", EACH SIDE OPEN WEB STL JST (2) L3x3x1/4" ANGLE BRACE L 3x3x1/4" DO NOT WELD COL TO ANGLE 3/16 3/16 3/16
