A concrete slab over metal deck bears on a structural steel beam with a minimum two-inch bearing width and a maximum nine-inch offset. The concrete is reinforced with continuous bar dowels, rebar laps per schedule, and size-four dowels measuring five feet in length spaced at twelve inches on center with a three-quarter-inch clearance. A continuous three-eighths-inch bent plate is anchored at the edge with size-four deformed bar anchors measuring two feet six inches in length at twelve inches on center, along with a continuous size-four reinforcing bar. Bidder-designed steel stairs and connections attach to the bent plate and are supplied by the stair manufacturer.
BRG 2" MIN 1/4 2-6 CONC OVER METAL DECK & REINF PER PLAN (SAME AT DECK PARALLEL) CLR 3/4" #4 DOWEL x 5'-0" @ 12"OC BIDDER DESIGNED STL STAIRS & CONN TO BENT PL BY STAIR SUPPLIER BRG 2" MIN 9" MAX SCHED 20/S4.01 LAP PER #4 CONT CONT BENT PL3/8 #4 DBA x 2'-6" @ 12"OC
