Pour closure plates of 1/8-inch or 10 gauge are provided at columns lacking stiffener plates at the proper elevation, aligning with the beam top flange. Additional closure plates and typical L3x3x3/16 or 10 gauge angles are detailed at the beam intersections with 3/16-inch fillet welds.
CLOSURE PL. 3/16 3/16 L3x3x3/16 OR 10 GA., TYP. 1/8" OR 10 GA. POUR COLUMNS THAT DON'T HAVE STIFFENER PLATES AT PROPER ELEVATION CLOSURE PLATES TO ALL BEAM TOP FLANGE
