Structural · S-YJBDG

Welded Corebrace at Foundation

Materials

Concrete Steel Masonry / CMU

Elements

Columns Floors / Slabs Foundations / Footings Connections / Plates

Connections

Gusset Plate Welded Connection

About this detail

A buckling-restrained brace connects to a steel column base and concrete foundation. A steel column anchors to a concrete foundation with a concrete block-out at the slab on grade. A gusset plate connects the buckling-restrained brace to the column, reinforced with stiffener plates welded on near side and far side as required. Five-sixteenth-inch fillet welds are applied on three sides, and gusset plate welds are designated as demand-critical welds. Base plate and anchor bolt information is referenced per structural elevations.
