This conceptual detail establishes the structural design parameters for an acoustic silencer support frame. The drawing specifies that the connection and framing design is delegated and must be submitted as a deferred submittal by others.
NOTE: DETAIL IS FOR CONCEPT PURPOSES ONLY. CONNECTION AND FRAMING OF SILENCER SUPPORT FRAME WILL BE A DELEGATED DESIGN/DEFERRED SUBMITTAL BY OTHERS.
Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
