The drawing details a 9.5mm thick steel plate (PL 9.5 300W) featuring a curved or quarter-circle profile with typical 10x45 degree chamfers. It includes centerlines and dimensions for three drilled holes (9.5 diameter) positioned for bolted connections. An elevation view shows the plate secured with threaded fasteners, nuts, and washers along its centerline.
Text on the drawing
CL CL CL 26 140 140 26 26 CHAMFER 10x45˚ TYP 1 HOLE 9.5Ø DRILL THRU ON ASSEMBLY ENLARGED DETAIL PL 9.5 300W
