A cold-formed steel wall bears above an HSS beam with a three-quarter-inch gap forming a drift and deflection joint. A bent plate connects the assembly to a non-bearing concrete masonry unit wall containing a bond beam. An angle member supports the cold-formed steel framing from the structural beam.
3/4" GAP 2-5 TYP. 1-6 TYP. DRIFT/DEFLECTION JOINT BENT PL. REF. 2/S5.52 NON-BEARING MCU WALL REF. PLAN ANGLE REF. 2/S7.11 BON BEAM REF. GENERAL STRUCTURAL NOTES BLOCK VENEER REF. ARCH CFS WALL REF. ELEVATION HSS BEAM REF. ELEVATION
