A steel column supports a joist girder framing into the structural grid. A steel joist bears above the girder while a metal stud track spans between supplemental channel supports. An exterior metal stud wall by others runs parallel to the column face. Reference callouts direct the builder to related details on sheet SE702 for additional information not shown.
MTL STUD WALL, BY OTHERS STL COL SE702 8 TYP JST GIRDER STL JST MTL STUD TRACK TO SPAN BTWN CHANNEL SUPPORTS PROVIDED FOR INFO NOT SHOWN, SEE DET AND / (8 SE702) / (7 SE702)
