A buckling-restrained brace connects to a structural steel column base assembly via a gusset plate and bolted connection. The steel column is welded to a base plate secured by anchor rods embedded in concrete. A gusset plate attaches to the column and base plate, receiving the buckling-restrained brace secured by manufacturer-specified bolts. Fillet welds join the gusset plate to the column and base plate according to design drawings.
2" TOC EL 100' - 0" COL, BASE PL & AHR RODS PER SCHED BRB AND BOLTS PER MFR SEE S-611 FOR ADDL INFO GUSSET PL1 WP GRID 3/8 3/8 DC TOC EL 98' - 6" 12" MAX 2' - 8" **
