Studrails are positioned perpendicular to the face of the interior rectangular concrete column on four sides with equal spacing. The first stud is placed two inches from the column face with subsequent studs spaced at three inches typical. Studrail lengths and column sizes are determined per the schedule and plan.
STUDRAIL TO BE POSITIONED PERP TO COL FACE A1 INTERIOR RECTANGULAR COLUMN - PLAN 3" TYP 1/2" TYP EQ EQ EQ EQ SEE STUDRAIL LENGTH PER SCHEDULE STUDRAILS TO BE PLACED PERP TO COLUMN FACE 3" SPACING TYP 2" TYP STUDRAILS ON 4 SIDES CL CONC COL - SEE PLAN FOR SIZE
