A wood beam connects to a timber column and shearwall assembly using two Simpson MST72 straps fastened with twenty-four 16d nails at each end. The column features a triple-stud configuration secured with 5/8-inch-diameter stud anchors spaced at 16 inches on center. A 6x14 number 1 timber member frames adjacent to the wall, with sheathing sized per plan.
BEAM PER PLAN SEE 21 SD4 (2) SIMPSON MST72 W/ (24) 16d NAILS EA END COLUMN PER PLAN 3x STUD W/ 5/8"Ø STUD ANCHORS @ 16"OC SHEATHING SEE PLAN 6x14 #1 7 - EQ EQ
