A glulam beam is set into a notched hole within a full-height cross-laminated timber wall panel. A shim gap is provided once the beam is set, maintaining specific clearances around the connection per the structural plan.
3 8 " CLR 3 8 " CLR 3" CLR SECTION A-A GLB PER PLAN NOTCH HOLE IN CLT WALL PANEL TO RECEIVE GLB. SHIM GAP ONCE BM IS SET FULL HT CLT WALL PANEL
