A one-quarter-inch by twenty-inch by eleven-and-one-half-inch shear plate connects via six one-and-one-quarter-inch diameter by four-and-three-quarter-inch A325N bolts. The shear plate is welded to a one-half-inch by fourteen-inch by ten-inch embed plate with five-eighths-inch welds. The embed plate is anchored into the reinforced concrete element using Grade 60 A706 number eight reinforcing bars welded directly to the embed.
PL1 14 / "X20" X 0'-11 12 / " SHEAR_PLATE 3" 3" 3" 58 / 58 / SHEAR PL TO EMBED 3" 6 - 1 14 / "Ø x 4 34 / " A325N FIN FLR 1'-2" PL2 12 / "X14" X 0'-10" EMBED_PLATE 3 34 / " REBAR#8 A706-60 REBAR#8 TO EMBED 1'-2" 3 34 / " 4" 4" 3" 2" 3 34 / " 2" 2"
