A wide-flange column connects to a framing beam with a high load connection per detail 29/S-503. A gusset plate at the work point accommodates a diagonal strut brace and a lower brace where required. A matching beam on the opposite side frames into the column flange when specified on plans.
CONNECTION NOTE: REFER TO CONNECTION FOR CALL-OUTS IN COMMON A C W.P. STRUT BRACE (WHERE OCCURS) COLUMN PER PLAN (WF WHERE OCCURS) HIGH LOAD CONN. PER BEAM OPP. SIDE (WHERE OCCURS) 4" 29/S-503
