This detail defines the dimensions and layout for a changeable messaging signage panel. The unit measures eighteen inches in width by eight and seven-eighths inches plus or minus in height. A one and five-eighths inch logo is positioned at the upper left corner, typical for the assembly. The panel is designated for a maximum of three lines of changeable messaging.
Text on the drawing
8 7/8"± 18" CHANGEABLE MESSAGING MAXIMUM 3 LINES BDS-3 1-5/8" LOGO, TYPICAL
