Cold-formed metal framing connections for headers and jambs use tracks and studs sized per the stud wall schedule. The double stud header section features two rows of number ten screws at twelve inches on center attaching track to track, with an ordinary track and a matching flat member, secured by number ten screws at each stud and each flange. The header to jamb connection requires trimming the flat stud flanges and bending the web to attach to the full-height uncut jamb with two number ten screws on both sides. A one-inch typical clearance and a three-inch dimension govern the layout.
(2) ROWS #10 SCREWS @ 12" O/C TRACK TO TRACK STUD #10 SCREW EA. STUD EA. FLANGE 3" (2) #10 SCREWS BOTH SIDES TO JAMB ORDINARY TRACK PER STUD WALL SCHEDULE FLAT MEMBER MATCHING STUD MATERIAL PER STUD WALL SCHEDULE FULL-HEIGHT JAMB DO NOT CUT OR DAMAGE TRIM TRACK WEB and EXTEND FLANGES TO LAP W/ SIDES OF JAMB TRIM FLAT STUD FLANGES and BEND WEB - ATTACH TO JAMB W/ (2) #10 SCREWS DOUBLE STUD HEADER SECTION__ 6D DOUBLE STUD HEADER TO JAMB CONNECTION__ 6C HEADER SECTION__ 6B HEADER TO JAMB CONNECCTION__ 6A 1" TYP.
