This precast concrete return wall section details a rectangular concrete member measuring 2 feet 4 inches by 1 foot 7 inches with a 2-inch clearance and a 1/2-inch joint against an adjacent panel. The main longitudinal reinforcement consists of four number 7 bars on each face, spaced equally. Transverse reinforcement is provided by number 4 two-piece ties with top ties spaced at 4 inches on center, though spiral or closed ties of the same size and spacing may be used as an alternative. A line of the panel below and an adjacent panel are indicated with dashed outlines to show relative positioning and joint spacing.
