A cold-formed steel continuous bottom track, sized at six inches by sixteen gauge, is secured with number ten self-tapping screws at six inches on center staggered. The track supports six by eighteen gauge metal studs designated as 600S162-43 spaced at sixteen inches on center. The assembly interfaces with a concrete over metal floor deck spanning to a steel beam sized per plan. Additional framing elements include wall sheathing and a window head detail aligned per architectural drawings.
A3 S511 C5 S511 A1 S602 A2 S511 A1 S511 AT PERPENDICULAR BEAM CONCRETE OVER METAL FLOOR DECK, SEE PLAN STEEL BEAM, SEE PLAN WALL SHEATHING, SEE ARCH 6"x16GAxCONT BOT TRACK WITH #10 STS AT 6" O.C.- STAGGERED SEE ARCH FOR WALL FINISH TOP OF WINDOW SEE ARCH 6x18GA. METAL STUDS (600S162-43) AT 16" O.C. B.O. WINDOW SEE ARCH SEE PLAN <12"
