The assembly illustrates a structural steel connection involving a hollow structural section member where the beam can be bent up or down. The connection is detailed with complete joint penetration welds as indicated by the weld symbol and callouts. This provides a rigid moment-resisting or structural framing connection between hollow structural section components.
Text on the drawing
BENT BEAM UP OR DOWN HSS MEMBER A CJP SCALE: NTS 3 TYPICAL HSS BEAM TO COLUMN CONNECTIONS STEL-HBEM-0001
