An L4x4x3/8 angle brace frames between hollow structural section members in a kicker connection. The diagonal kicker connects back to an HSS5x5x5/16 column assembly. Elevation dimensions and structural levels are indicated throughout the plan view.
S-156 7 S-156 5 (113'-0") (116'-0") (B/STL 112'-9 1/2") CONN TO HSS5x5 15/S-156 SIM CONN TO POST 9/S-156 SIM (113'-0") (116'-0") S-156 6 HSS5x5x5/16 L4x4x3/8 L4x4x3/8 KICKER HSS5x5x5/16 (116'-0") 4'-6" HSS5x5x5/16 0" 9 S-156
