This structural drawing details a precast concrete trash enclosure wall panel supported by a continuous concrete footing with two continuous number five reinforcing bars and a two-inch grout layer. The six-inch thick concrete trash enclosure slab ties into the footing and features number three reinforcing bars at eighteen inches on center each way. The precast wall panel is reinforced with number four vertical bars at twelve inches on center at the center of the panel, number four horizontal bars at twelve inches on center, and two continuous number five bars at the top. Erection pads are located at the footing level, and a note indicates projection vertical reinforcement at the bottom of the panel between erection pads. A separate detail on the right shows the roof framing above, consisting of steel channels, roof metal deck fastened with Teks screws per framing plan, hollow structural section beams or C12 channels, and hollow structural section posts bearing on concrete foundations.
