Continuous slab dowels and slab reinforcement detailed per plan tie into vertical wall reinforcement sized per the southwest elevation at the concrete wall and concrete floor slab intersection. Form savers are installed at the wall-slab interface with designated spacing constraints. Three-quarter-inch deep by three-and-a-half-inch high by one-foot long shear keys are spaced at twenty-four inches on center along the vertical joint. Wall thickness and floor elevation are defined per plan.
PER PLAN EL 24" 24 3/8" 8" 5" 4" MAX PER PLAN WALL THICK PER PLAN Lsb 3/4" DEEP x 3 1/2" HIGH x 1'-0" LONG KEYS AT 24" OC SLAB DWL PER PLAN REINF PER SW ELEVATION FORM SAVERS, SEE NOTE 1 SLAB DWL PER PLAN SLAB REINF PER PLAN REINF PER SW ELEVATION SLAB REINF PER PLAN TYP
