A metal joist frames into a W-shape steel beam supporting a sloped roof assembly with roof sheathing. The joist connects via a 'WP' sloped hanger welded to the top flanges of the steel beam with three-sixteenths inch by one and one-half inch minimum fillet welds on each side. Steel shims are placed beneath the joist bearing as needed to achieve the proper top of joist elevation.
JOIST TO W-FLANGE STEEL BEAM ROOF SHEATHING SLOPE - SEE ARCH METAL JOIST - SEE PLAN 'WP' SLOPED HANGER W/ 3/16" x 1-1/2" MIN. FILLET WELD AT EA. SIDE OF HANGER TOP FLANGES TO STL. BEAM - SEE MANF'R. STL. BEAM - SEE PLAN STL. SHIM AS NEEDED TO ACHIEVE PROPER TOP OF JOIST ELEVATION
