The top course of a masonry wall features a continuous 8-inch bond beam reinforced with two No. 5 bars, while vertical reinforcement consists of No. 5 bars spaced at 24 inches on center.
F9.5 1 #5 @ 24" O,C. VERT W/ CONT. 8" BOND BEAM W/ (2) #5 AT TOP COURSE OF WALL.
