A structural steel beam frames into the web of a wide flange column where the beam fits inside the column profile. A typical shear plate connects the beam web to the column web per plan. The top of steel and column sizes are sized per plan.
BEAM TO WIDE FLANGE COLUMN FLANGE SHEAR PLATE INFORMATION PER TYPICAL SHEAR PLATE CONNECTION. COL PER PLAN TYP SHEAR PL CONN BEAM PER PLAN, TYP CL COL BEAM TO WIDE FLANGE COLUMN WEB - OPTION 1 (BEAM FITS INSIDE COLUMN) SHEAR PLATE INFORMATION PER TYPICAL SHEAR PLATE CONNECTION. BEAM WHERE OCCURS PER PLAN T/STL PER PLAN
