P1001 silencer support frame posts are spaced at four feet on center maximum and secured to an eight-inch slab-on-grade. A P1000 silencer support frame brace ties into the post assembly. Each support frame post is anchored using a P2073A square base plate fastened with four three-eighths-inch-diameter DeWalt Snake+ anchors featuring a one-and-five-eighths-inch nominal embedment. The detail notes that the design is for concept purposes only, with connection and framing subject to a delegated design and deferred submittal by others.
'P1001' SILENCER SUPPORT FRAME POST, TYP. @ 4'-0" O.C., MAX. 'P2073A' SQ W/ (4) 3/8" ⌀ DEWALT SNAKE+ ANCHORS W/ 1-5/8" NOM. EMBED, TYP. AT EA SUPPORT FRAME POST 'P1000' SILENCER SUPPORT FRAME BRACE 8" SLAB-ON-GRADE NOTE: DETAIL IS FOR CONCEPT PURPOSES ONLY. CONNECTION AND FRAMING OF SILENCER SUPPORT FRAME WILL BE A DELEGATED DESIGN/DEFERRED SUBMITTAL BY OTHERS.
