A structural steel beam frames onto a vertical column per plan, terminating at a one-half-inch by six-inch by one-foot-zero-inch cap plate welded to the column top with a five-sixteenth-inch fillet weld on three sides. The beam is connected to the cap plate using a pair of L5x3x3/8 by zero-foot-six-inch long vertical leg angles attached with two five-eighth-inch diameter bolts spaced at three inches on center. The connection assembly aligns along the centerline of the column and beam.
5/16 BEAM PER PLAN L5x3x3/8x 0'-6" (LLV) W/ (2) 5/8" ⌀ BOLTS @ 3"oc CAP PL 1/2"x6"x1'-0" 1 1/2" 5/16 (1/4) (3) sides COL. PER PLAN CL COL. / BEAM 4 28 5210
