A concrete pilaster is integrated with a construction or contraction joint within the foundation wall. An isolation joint featuring two layers of thirty-pound felt separates the wall sections. A concrete infill measuring a minimum of three inches is placed between the pilaster and the isolation joint.
PILASTER CONSTRUCTION JOINT OR CONTRACTION JOINT FOUNDATION WALL ISOLATION JOINT WITH 2 LAYERS OF 30# FELT CONCRETE INFILL BETWEEN PILASTER AND ISOLATION JOINT MIN 3"
