A pressure-treated 4x Douglas Fir No. 1 or 3-1/2 inch parallel strand lumber shaped wood sleeper, fire-treated as required per architecture, fastens to a metal deck. A 3/4-inch diameter welded threaded stud anchors the mechanical unit at 24 inches on center and within 12 inches of ends, with a minimum of two studs per side opening. Number 12 wood screws provide connection with a 2-inch minimum penetration at 4 inches on center and within 4 inches of ends, with a minimum of three per side. Where the deck runs continuous, a gauge plate is provided for deck connection per plan requirements.
B SECTION PER 2/S6.02 #12 WOOD SCREW W/ 2" MIN PENETRATION AT 4" OC AND WITHIN 4" OF ENDS (3 MIN PER SIDE) DECK PER PLAN TYP PT 4x DF#1 OR 3 1/2" PSL SHAPED WOOD SLEEPER (FIRE TREATED AS REQ'D PER ARCH) MECH UNIT 3/4"ø WELDED THREADED STUD @ 24" OC AND WITHIN 12" OF ENDS (MIN 2 PER SIDE OPENING) 8" MAX AS REQ'D COUNTERSINK 2" MAX 1 1/2" 1 1/2" MIN WHERE DECK RUNS CONTINUOUS PROVIDE GAUGE PL PER 2/S6.02 FOR DECK CONN
