An interior stair landing features a channel stringer supporting a ten-gauge metal pan filled with concrete. The landing framing connects to a hollow structural section member using four seven-eighth-inch high-strength bolts and a three-eighth-inch stiffener plate. A guardrail is mounted adjacent to the landing assembly, maintaining standard clearances and edge returns.
2" 1 1/2" C12 SEE STAIR PLANS C8 SEE STAIR PLANS 10 GA METAL PAN TYP AT LANDING HSS SEE STAIR PLANS INTERIOR STRINGER AT LANDING GUARDRAIL 3/8" STIFFENER PLATE (4) 7/8" HSB HSS TO C12 UP T.O. LANDING TYP TYP 1½" MIN RETURN TYP 1½" CONC FILL
