A continuous one-quarter-inch by eight-inch by four-inch bent plate is welded to a wide-flange steel beam supporting a roof metal deck. Concrete on metal deck carries a concrete mechanical equipment pad sized per plan with a sloped surface for drainage. Reinforcing bars of size number three spaced at twelve inches on center are welded to the bent plate and lap with the mechanical equipment pad reinforcement maintaining a one-and-one-half-inch minimum clearance.
ROOF MTL. DECK PER PLAN #3 @ 12" O.C. WELDED TO BENT PL TO LAP W/ MEP PAD REINF. WF BM. PER PLAN PER SCH. FOR DECK WELDS CONC. MEP PAD PER PLAN SLOPE TO DRAING (S.A.D.) 1/4"x8"x4" CONT. BENT PL CONC. ON MTL. DECK PER PLAN CLR. 1 1/2" Ld, MIN. MEP ZONE AND PAD PER PLAN 3/16 3-12 3/16
