A steel column extends upward from a steel base plate set upon one and a half inches of non-shrink grout atop a concrete foundation wall and footing. A concrete blockout surrounds the base plate assembly at the exterior slab or grade transition. Anchor bolts secure the base plate into the foundation wall, and a five-sixteenths fillet weld connects the column base to the plate.
EXTERIOR SLAB OR GRADE, SEE ARCH CONCRETE WALL, SEE PLAN AND SCHED STEEL COLUMN, SEE PLAN AND SCHEDULE STEEL BASE PLATE (SEE SCHED) ON 1 1/2" NON-SHRINK GROUT CONCRETE BLOCKOUT CONCRETE WALL, SEE PLAN AND SCHED CONCRETE FOOTING, SEE PLAN AND SCHED LINE OF WALL BEYOND 5/16 1 S502 8" FROM TOP OF FDN WALL
