A hollow structural section purlin bears onto a truss purlin secured by two rows of pneumtek pins at beam-nail spacing with four lines where indicated. The connection includes a one-eighth inch fillet weld on one and one-half inch spacing. An HSS splice is located per plan with reference to detail twelve. Section B-B cuts through the assembly showing a two and one-half inch dimension.
B-B 2 1/2" 12 - HSS SEE PLAN FOR SPLICE WHERE OCCURS SEE 1/8 1 1/2 TRUSS PURLIN (2) ROWS OF PNEUTEK PINS AT BN SPACING (4 LINES WHERE BN
