A W18X35 wide flange steel beam frames into a shaft wall assembly with dimensions sized per plan typically unless noted otherwise. Reference bubbles direct coordination to sheets SD6.2 and SD7.8.
P2 P2 TYP U.N.O. W18X35 [26] 7A SD7.8 SEE PLAN SEE PLAN SEE PLAN SEE PLAN SEE PLAN 17 SD6.2 9A SD6.2
