An open-web steel joist bears directly on the top flange of a structural steel beam sized per plan. A four-inch top plate connects the assembly with bolted hardware extending through the top chord bearing plate. A bolt secures the joist shoe to the supporting beam flange.
STEEL BEAM PER PLAN B.N. 4x TOP PL SEE 5/-
