Steel beams frame into a steel column with bolted shear tabs while steel deck spans across the assembly. A steel strap plate is centered over the column cap plate and welded to the framing members to act as a drag strut. Typical weld symbols connect the steel deck and structural components.
JK1RSB12 STEEL STRAP PLATE: __"x__"x__" CENTER OVER COLUMN STEEL CAP PLATE STEEL COLUMN STEEL DECK TYP TYP TYP STEEL BEAM STEEL BEAM STEEL BEAM
