A concrete slab on metal deck runs perpendicular to an exterior precast concrete wall, supported by a steel framing beam. The assembly ties into the precast panel using a three-eighths-inch by seven-and-a-half-inch continuous bent plate welded to a vertical three-eighths-inch by four-inch continuous plate embedded in the wall. Connection hardware features one-half-inch diameter by five-inch long headed studs spaced at twelve inches on center, staggered with vertical placement. An out-of-plane lateral connection by the precast manufacturer incorporates a three-and-a-half-inch minimum horizontal slotted hole providing a two-kip out-of-plane reaction with three-quarters of an inch of clearance, leaving the connection free of vertical or in-plane support. Fillet welds of one-quarter-inch size at three-inch to twelve-inch spacing secure the steel components as specified on the drawings.
GRID GRID CONCRETE SLAB ON METAL DECK SEE PLAN 1/4 3/12 STEEL BEAM REF PLAN T/ SLAB SEE PLAN 3" 4" 3/8" BENT PL X 7/12" x CONT. SLAB REINFORCING 1/2" DIA X 5" LONG HS @ 12" O.C. STAGGERED w/ VERTICAL 3/8" X 4" CONT PLATE 1/4 3-12 1/4 3-12 PRECAST PANEL REF ARCH DWGS OUT OF PLAN LATERAL CONNECTION BY P/C MFR (NO VERTICAL OR IN-PLANE SUPPORT) 3 1/2'' MIN HORIZONTAL SLOTTED HOLE (2 KIP OUT OF PLANE) 1/2" DIA X 5" LONG HS @ 12" O.C. BY P/C MFR 3/4" CLR OUT OF PLANE REACTION PER SCHEDULE CONNECTION BY PRECAST SUPPLIER SEE ARCH SEE ARCH SEE PLAN NOTES:
