An incoming structural brace connects directly to a column web utilizing a base plate assembly with a nine-anchor rod configuration. Washer plates per AISC Table 14-2 are positioned at three-quarter-inch anchor rods, with equal spacing across the base plate dimensions. Stiffener plates sized per schedule match the non-gusset side and feature complete joint penetration welds typically. A one-inch diameter grout hole is provided at the contractor option near the center. Additional anchor rods include washer plate A designations for alignment.
"W"/2 6" 6" 6" TYP 8" INCOMING BRACE TO COLUMN WEB - (9) AR CONFIGURATION BASE PL 1"ø GROUT HOLE AT CONTR OPT AR W/ WASHER PL "A" WASHER PL PER AISC TABLE 14-2 AT 3/4"ø AR EQ EQ "L" EQ EQ CJP, TYP 13 3/8" TO MATCH NON- GUSSET SIDE STIFF PL PER SCHED
