A sixteen millimeter thick gusset plate connects a diagonal brace to a structural steel column and beam assembly. The gusset plate is welded to the column with a ten millimeter fillet weld and to the beam with a ten millimeter fillet weld, while the brace connects to the gusset plate with a ten millimeter weld. A shear cleat connection joins the beam to the column flange using three bolts. A composite metal deck with shear studs is shown above the framing members.
50 MIN 50 MIN 16mm GUSSET PLATE 200 MIN 200 MIN BRACE PER ELEVATION WORKPOINT / 1 S6.0 SEE DETAIL FOR CLEAT CONNECTION INFORMATION SEE DETAIL FOR SHEAR STUD INFORMATION / 2 S6.0 COMFLOR WHERE OCCURS, NOT SHOWN FOR CLARITY BEAM PER ELEVATION COLUMN PER ELEVATION BEAM AT 'SIM' 160 MIN 10 GUSSET TO COLUMN 10 GUSSET TO BEAM 25, TYP. 10 BRACE TO GUSSET VARIES
