An HSS8x4 vertical column supports intersecting HSS10x4 girts configured with maximum eccentricity per note on S216. A 1/4-inch plate is inset 1/4 inch from the HSS end and secured with 3/16-inch near-side and far-side fillet welds. Additional 1/4-inch and 5/16-inch fillet welds connect the girt assemblies to the main column member. The top of steel elevations for the girts and column base vary per plan.
PER PLAN TOS NS/FS 5/16 3/16 NS/FS (1/4) PER PLAN TOS HSS8x4 TYP 17" GIRT PER PLAN 1/4 PL1/4 INSET 1/4" FROM HSS END HSS10x4 PER PLAN TOS VARIES GIRT PER PLAN 20 S602 4 S602 MAX ECCENTRICITY PER NOTE ON S216
