The top track of a wall partition connects to a twenty gauge minimum metal roof deck oriented perpendicularly to the track. Staggered shotpins anchor the top track at the lower flute of the deck with spacing governed by the partition schedule. Vertical studs frame into the top track as specified in the partition schedule. Shotpins may be substituted with self-tapping metal screws per the schedule when required.
TOP TRACK PER PARTITION SCHEDULE VERT STUD PER PARTITION SCHEDULE WHEN TOP TRACK PERPENDICULAR TO FLUTE SHOTPIN STAGGERED CTR AT LOWER FLUTE, SPACING PER SCHED 20GA MIN DECK BY OTHERS SIM @ METAL ROOF DECK; SUBSTITUTE SHOTPINS W/ SMS PER SCHEDULE
